Specification parameter:
Type No.: VH40-24A222 power rate: 40W
Input voltage: AC170-265V frequency range: 50-60Hz
Output voltage: DC24V output current: 1.67A
Efficiency: 85% PF value: 0.55
Working temperature: -30-50 degrees Celsius storage temperature: -40-80
Structure size:
Power supply size: mm L222*W30*H21 shell material: aluminum alloy
Protection level: IP67
Input wire: VDE H03VV-F 3G0.75m & M Brown Blue & Yellow / green (200mm)
Output wire: VDE H03VV-F 2 * 0.75m square meters Brown & Blue (200mm)
Application range:
LED light source, the LED lamp with power supply, led wash wall lamp power supply, LED power supply module, LED guardrail tube, LED light box advertising power lighting engineering.
Product features:
1 this product is a separate program power supply, using constant current constant voltage chip design, high conversion efficiency, low temperature rise, high precision.
2 built in anti electromagnetic interference filter circuit, anti-interference performance is good, reliable performance is high.
3 DC ripple small, high efficiency, low power consumption, low heat, long service life.
4 products with well-known brands of raw materials, effectively ensure the quality of the product.
5 the input voltage range is wide, (170-265V) in accordance with the global standard of use.
6 good insulation performance, high resistance to electrical strength. (pressure 3750V).
7 products with short circuit, overload, over voltage and no load protection function, the automatic recovery after reduction.
8.100% full load aging test.
9 all materials are not (and not beyond the provisions of the limits) of the European restrictions / disable cadmium, chromium, lead, mercury, PBB, PBDE six kinds of toxic substances.
10 the first grade insulation performance is good, high frequency transformer 100% using vacuum infiltration.
11 aluminum alloy shell structure, the product does not rust, good heat radiation, low temperature rise, and effectively ensure the product waterproof grade.
Matters needing attention:
1 do not connect the input and output terminals, so as to avoid the bad LED power supply.
2 LED waterproof power supply case ground wire (FG) must be grounded in order to ensure the safety; non error will be connected to the ground wire (FG) on the zero line.
3 LED power must be used in a suitable environment, working in harsh environments is likely to shorten the life of the power supply.
4 in order to achieve the best cooling effect, the LED power supply is recommended to install the air flow in a good location, or installed in the metal chassis.
5 please correctly match the power supply with the light source, so as to avoid the lamp can not work properly or damaged lamps and power supply, resulting in loss of.
